When OEM Doesn't Mean OEM: A Case Study in Injector Testing

A customer recently brought his excavator to our shop for injector diagnostics. The machine, a well-known Japanese brand, had clocked over 16,000 hours and was undergoing cylinder head repairs unrelated to the fuel system. The engine, a large American-made model, had its cylinder head removed, rebuilt, and reinstalled. Given the machine’s high hours and the scope of the repairs, the mechanic opted to replace the injectors as a precautionary measure. He sourced the injectors from the manufacturer’s authorized parts supplier, ensuring the process followed all recommended procedures.

The Issue at Hand

Despite the meticulous approach, the customer encountered a significant problem. After reassembly, the engine ran smoothly for approximately 20 seconds before emitting dense clouds of black smoke. Concerned, he shut it down within the next 10–15 seconds. Fearing catastrophic engine damage, he conducted another compression test, which yielded excellent results. This left him questioning whether he had inadvertently contaminated the fuel system or made an error during installation. To rule out these possibilities, he brought the injectors to our facility for comprehensive testing.

The Testing Process

The injectors in question are Bosch-manufactured units, commonly used in this engine model. Our shop is equipped with certified Bosch testing machinery, allowing us to evaluate the injectors thoroughly. Each injector undergoes a multi-stage assessment, including an initial pressure test to detect leaks, followed by evaluations at idle, mid-load, and heavy-load conditions. We also test for pilot injection performance and other application-specific parameters. At every stage, we measure both fuel delivery and return flow to ensure accuracy.

This detailed testing process helps us identify whether the injectors are functioning correctly or if they are the root cause of the issue. In this case, the customer’s concerns about contamination or installation errors could be systematically ruled out, allowing us to focus on other potential causes of the problem.
